Whilst Drag Racing is not a motorsport that MCA Suspension is well known for, we have actually had a lot of success with top-level teams running in the 6s. We decided to take this success and experience and use it to develop drag racing-specific products for a wider range of vehicles. This resulted in the MCA Suspension Pro Drag product.
Designed specifically for Drag Radials used on prepped track surfaces,
thanks to our latest Fusion V3.0 Valving, we’ve managed to design a
product versatile enough to also be used on unprepared surfaces as well
as Roll Racing events.
Specifications
- Brand: MCA Suspension
- Range: MCA Pro Drag
- Vehicle: Toyota Chaser JZX90
- Spring Rate: Front: 21kg Rear: 6kg
- Specifications: -Designed, Developed, Assembled & Fully Supported in Australia. -3 Year Platinum Warranty. -Fusion Valving Technology V2. -12 Clicks of Hard/Soft Damper Adjuster (Bump & Rebound together). -Camber Adjustment via top mount (where possible, see vehicle-specific details section). -Camber Washer Bottom Mounts (where possible, see vehicle-specific details section). -Damper Adjuster Extenders (where possible, see vehicle-specific details section). -Wheel travel range adjustment via the bottom mount (pre-set by MCA). -Height adjustment via spring seat position (base height adjustment is flawed). -Suggested Height Adjustment Range: depends on the specifics of the order. -Reinforced double gusseted lower mounts (where applicable, see vehicle-specific details section). -Helper Springs to keep the main spring captive at all times. -Latest Rugged Spec internal sealing designs and components. -Superior Monotube design.
- Suitable Applications: -Street driving with a firm but adequate ride quality -Enjoyable spirited driving -High-level spirited driving -Light/Medium Motorsport usage -Factory height down to tyre up inside fender 15mm (estimate)
- Front: Coilover design, Spring rate 21kg.
- Rear: Coilover design, 20cm damper adjuster extenders, Spring rate 6kg.
- Part Number: TOYCHAJZX90-PDRAG
MCA coilovers are custom assembled to order in Australia — spring rates and valving are specified for your car and how you use it. Please confirm fitment before ordering.
