034Motorsport Density Line Adjustable Rear Toe Links, B9/B9.5 Audi A4/S4/RS4, A5/S5/RS5
These Density Line adjustable rear toe links replace the fixed, stamped steel factory toe links on B9 and B9.5 Audi A4, S4, RS4, A5, S5, RS5 and A4 Allroad models. They allow precise on-car toe adjustment beyond the factory range, which 034Motorsport notes is especially useful after large ride height changes and when setting up for track use or tyre wear. The rod ends use Density Line 90 durometer rubber bushings to hold suspension geometry under hard cornering, paired with black anodised 6061-T6 aluminium tubes and stainless steel spacers. 034Motorsport tested the links on the street and track on its B9 S4 development car, and they drop in as direct replacements that are fully serviceable and rebuildable.
Features
- CNC-machined 6061-T6 aluminium tubes, black anodised
- Zinc-plated forged steel threaded rod ends
- 90 durometer rubber bushings reduce deflection
- Toe adjustment beyond the factory range
- Easy, precise on-car adjustment
- Direct drop-in replacement, sold as a pair
Specifications
- Brand: 034Motorsport
- Product Type: Adjustable Rear Toe Links
- Link Tubes: CNC-machined 6061-T6 aluminium, black anodised
- Rod Ends: Zinc-plated forged steel, 90 durometer rubber bushings
- Spacers: CNC-machined stainless steel
- Quantity: Pair
- OE Interchange: 8W0501529D, 8W0501530D
- Part Number: 034-407-1006
Vehicle Compatibility: 7 applications across 1 make. Select a make to view.
Audi (7)
| Model | Variant | Engine | Years |
|---|---|---|---|
| A4 | B9/B9.5 | 2.0 TFSI | 2017-on |
| A4 Allroad | B9/B9.5 | 2.0 TFSI | 2017-on |
| A5 | B9/B9.5 | 2.0 TFSI | 2018-on |
| S4 | B9 | 3.0 TFSI | 2018-on |
| S5 | B9/B9.5 | 3.0 TFSI | 2018-on |
| RS4 | B9/B9.5 | ||
| RS5 | B9/B9.5 | 2.9 TFSI | 2018-on |
Please confirm fitment against your vehicle before ordering. Contact us if you need help selecting the right part.
