034Motorsport Volkswagen Golf MK8R & Audi S3 8Y 2-Piece Floating Rear Brake Rotor 355mm Upgrade - 034-301-2012
This 355x22mm 2-piece floating rear brake rotor kit upgrades the rear brakes on the Mk8 Volkswagen Golf R and the 8Y Audi S3, with the Mk8 GTI and 8Y RS3 also listed in the fitment table. It is a complete replacement rotor and caliper carrier kit that works with the factory rear calipers and raises rotor diameter from 310mm to 355mm. 034Motorsport quotes about 13.5 lb per rotor against 15.0 lb for the factory rotor, a saving of 1.5 lb of rotational weight at each corner, and uses 72 directionally curved vanes to flow cooling air through the disc. The hats are 6061-T6 aluminium with Type III hard anodising, the rings are CM-250 special alloy with a J-slotted face, and the brand notes that brake dust shields must be removed or modified to fit the larger rotors.
Features
- Rotor diameter increased from 310mm to 355mm
- About 13.5 lb per rotor against 15.0 lb OE
- Floating 2-piece design with replaceable rotor rings
- 6061-T6 aluminium hats with Type III hard anodising
- CM-250 special alloy rings with J-slotted friction face
- 72 directionally curved vanes
- Caliper carrier conversion brackets included, red or blue
Specifications
- Brand: 034Motorsport
- Product Type: 2-Piece Floating Rear Brake Rotor Kit
- Rotor Size: 355x22mm (OE 310mm diameter)
- Weight: Approximately 13.5 lb per rotor (OE 15.0 lb)
- Hat and Mounting: 6061-T6 aircraft specification aluminium hat with Type III hard anodising; high-strength alloy steel floating bobbins
- Rotor Ring: CM-250 special alloy, J-slotted friction face, 72 directionally curved vanes, replaceable
- Colour: Red or Blue caliper carrier conversion brackets; anodised colour can vary from batch to batch, per 034Motorsport
- Includes: 355x22mm 2-piece floating rear rotor pair, caliper carrier conversion brackets (red or blue)
- Installation Note: Brake dust shields must be removed or modified to run the upsized rotors
- Part Number: 034-301-2012-RED (Red), 034-301-2012-BLU (Blue)
Vehicle Compatibility: 4 applications across 2 makes. Select a make to view.
Audi (2)
| Model | Variant | Engine | Years | Notes |
|---|---|---|---|---|
| S3 | 8Y | 2.0 TFSI | 2022-on | Brake dust shields must be removed or modified |
| RS3 | 8Y | 2.5 TFSI | 2022-on | Brake dust shields must be removed or modified |
Volkswagen (2)
| Model | Variant | Engine | Years | Notes |
|---|---|---|---|---|
| Golf R | Mk8 | 2.0T Gen4 | 2021-on | Brake dust shields must be removed or modified |
| Golf GTI | Mk8 | 2.0T Gen4 | 2022-on | Brake dust shields must be removed or modified |
Images shown are generic and for illustration only. The part supplied may differ in appearance.
Please confirm fitment against your vehicle before ordering. Contact us if you need help selecting the right part.
