This billet tunnel brace replaces the shallow-fitting factory driveshaft tunnel brace on B8 and B8.5 Audi A4, S4, RS4, A5, S5 and RS5 models to give aftermarket exhausts more room. It is CNC machined from 6061-T6 billet aluminium, finished in bright black anodising with a laser-etched 034Motorsport logo, and is stiffer than the OE stamped steel part. 034Motorsport says it increases exhaust clearance by 5mm, allowing an aftermarket exhaust up to half an inch larger in diameter to be fitted without excessive rattling or vibration. An integrated aeroflap maintains the OE underbody aerodynamics, and the brand says the brace adds no NVH.
Features
- CNC machined from billet 6061-T6 aluminium
- Bright black anodising with laser-etched logo
- 5mm more exhaust clearance than the OE part
- Stiffer than the OE stamped steel brace
- Integrated aeroflap maintains OE underbody aerodynamics
- No added NVH, per 034Motorsport
Specifications
- Brand: 034Motorsport
- Product Type: Driveshaft Tunnel Brace
- Material: CNC machined billet 6061-T6 aluminium
- Finish: Bright black anodised, laser-etched 034Motorsport logo
- Exhaust Clearance: 5mm more than the OE part, up to half an inch larger exhaust diameter
- Includes: Billet tunnel brace, mounting hardware (4 x Grade 12.9 M10 socket head screws)
- Part Number: 034-603-0030
Vehicle Compatibility: 7 applications across 1 make. Select a make to view.
Audi (7)
| Model | Variant | Engine | Years |
|---|---|---|---|
| A4 | B8/B8.5 | 2.0 TFSI, 3.2 FSI | 2009-2016 |
| A5 | B8/B8.5 | 3.2 FSI | 2008-2017 |
| Allroad | B8/B8.5 | 2.0 TFSI | 2010-2016 |
| RS4 | B8 | 4.2 FSI | 2012-2015 |
| RS5 | B8/B8.5 | 4.2 FSI | 2010-2017 |
| S4 | B8/B8.5 | 3.0 TFSI | 2010-2017 |
| S5 | B8/B8.5 | 4.2 FSI | 2008-2017 |
Please confirm fitment against your vehicle before ordering. Contact us if you need help selecting the right part.
