Koyorad Performance Radiator: Mazda RX-7 FB S3 1983-1985

Regular price $744.99

Seen this item cheaper somewhere else? Send us the link and we'll do our best to match or beat the price. We'll reply by email.

Product details
  • Type Engine Components
  • Vendor Koyorad
  • SKU HH063146

This radiator is a direct replacement for the factory unit on the Mazda RX-7 FB Series 3, 1983-1985 including the GSL-SE, in 2-door coupe form. Koyorad says its higher-capacity aluminium core cools better under hard driving. It is built for manual cars, and automatic cars will need an external transmission cooler. The tubes, fins, headers and brackets are brazed together in a Nocolok furnace, each unit is hand Heliarc welded, and a billet filler neck is fitted.

Features

  • Higher-capacity aluminium core for better cooling
  • Nocolok furnace brazing of tubes, fins, headers and brackets
  • Precision-machined billet filler neck on every unit
  • Mounting points for fan shrouds, hoses and top and bottom pins
  • Each radiator individually Heliarc welded by hand
  • M12 x 1.25 provision for low coolant sensor on top tank centre
  • No emissions switch provision on driver's side bottom tank

Specifications

  • Brand: Koyorad
  • Product Type: Performance Radiator
  • Core Material: Aluminium
  • Brazing: Nocolok furnace
  • Welding: Hand Heliarc welded
  • Filler Neck: Billet
  • Sensor Provision: M12 x 1.25 low coolant sensor, top tank centre
  • Emissions Switch Provision: None on driver's side bottom tank
  • Transmission: Manual (automatic needs an external transmission cooler)
  • Part Number: HH063146

Vehicle Compatibility: 1 application across 1 make. Select a make to view.

Mazda (1)
Model Variant Engine Years Notes
RX-7 FB Series 3 (2D Coupe, incl. GSL-SE) 1983-1985 Manual; automatic needs an external transmission cooler

Images shown are generic and for illustration only. The part supplied may differ in appearance.

Please confirm fitment against your vehicle before ordering. Contact us if you need help selecting the right part.
