MCA Reds Coilovers - BMW M3 M3 E46
This item needs to be ordered in
Heads up, this product isn't in stock for immediate dispatch. It will need to be ordered in (estimated 1–4 weeks) before it ships. Would you like to continue?
- Type Coilovers
- Vendor MCA Suspension
- SKU BMWE46M3-RS-CS
MCA Reds is MCA Suspension's long-running motorsport coilover range, originally developed for circuit, time attack, drift and drag use. Every kit for the BMW M3 M3 E46 is built to order in MCA's Brisbane workshop, with valving and spring rates chosen to suit the car's modifications and how it will be driven, from track-focused to comfortable street setups. The monotube dampers use Fusion V3.0 valving with 12 clicks of adjustment, and each damper is tested and tuned on a damper dyno before dispatch. MCA backs the Reds with a three-year transferable warranty that also covers motorsport use.
Features
- Monotube dampers with MCA's Rugged Spec internal sealing
- Fusion V3.0 valving
- 12-click damper adjuster (bump and rebound adjusted together)
- Ride height set by spring seat position
- Camber top mounts and camber washer bottom mounts where the vehicle allows
- Helper springs keep the main springs captive
- Dyno tested during assembly
- Can be rebuilt, revalved and re-sprung later
Specifications
- Brand: MCA Suspension
- Product Type: Coilovers
- Range: MCA Reds
- Damper Type: Monotube
- Damping Adjustment: 12 clicks (bump and rebound together)
- Valving: Specified by MCA per order
- Spring Rates: Custom, based on information provided to MCA
- Front Layout: Non-inverted strut design, Camber tops, Custom valving based on information provided to MCA
- Rear Layout: Separate spring & damper design, Custom valving based on information provided to MCA
- Kit Options: Complete Set, Front Dampers Only, Rear Dampers Only
- Height Adjustment: Spring seat
- Intended Use: Race
- Assembled In: Australia
- Warranty: 3 years, transferable
- Part Number: BMWE46M3-RS
Vehicle Compatibility: 1 application across 1 make. Select a make to view.
BMW (1)
| Model | Variant | Engine | Years |
|---|---|---|---|
| M3 M3 E46 |
Image shown is generic and for illustration only. The part supplied may differ in appearance.
Please confirm fitment against your vehicle before ordering. Contact us if you need help selecting the right part.
