MOTON Linear Racing Springs - 130 Series (130mm x 61mm ID)
Order In
MOTON Suspension

MOTON Linear Racing Springs - 130 Series (130mm x 61mm ID)

$234.99
Spring Spec- Length | Rate | ID

Seen this item cheaper somewhere else? Send us the link and we'll do our best to match or beat the price. We'll reply by email.

Product details
  • Vendor MOTON Suspension
  • SKU AST-130-50-61
Description

Moton Linear Racing Springs

Premium 130-Series Replacement Springs (61mm ID)

Engineered for professional motorsport dampers, these 130mm length linear springs offer the precision and predictable handling required for AST and Moton coilover systems. Manufactured from high-tensile chrome silicone steel to ensure maximum travel with minimum weight.

Lo Open Length (mm)
R Spring Rate (N/mm)
Di Inside Diameter (mm)
Sn Block Length (mm)
Fn Force at Block (N)
St Usable Stroke (mm)
Part Number Lo R Di Sn Fn St
AST-130-50-61 130 50 61 47 4150 83
AST-130-60-61 130 60 61 50 4800 80
AST-130-70-61 130 70 61 50 5600 80
AST-130-80-61 130 80 61 54 6080 76
AST-130-90-61 130 90 61 54 6840 76
AST-130-100-61 130 100 61 59 7100 71
AST-130-110-61 130 110 61 60 7700 70
AST-130-120-61 130 120 61 60 8400 70
AST-130-130-61 130 130 61 62 8840 68
AST-130-140-61 130 140 61 63 9380 67
AST-130-150-61 130 150 61 64 9900 66
AST-130-160-61 130 160 61 66 10240 64
AST-130-170-61 130 170 61 68 10540 62
AST-130-180-61 130 180 61 70 10800 60
AST-130-190-61 130 190 61 67 11970 63
AST-130-200-61 130 200 61 69 12200 61
AST-130-220-61 130 220 61 73 12540 57
AST-130-240-61 130 240 61 73 13680 57
AST-130-260-61 130 260 61 78 13520 52
AST-130-280-61 130 280 61 74 15680 56
AST-130-300-61 130 300 61 79 15300 51
AST-130-320-61 130 320 61 76 17280 54
AST-130-340-61 130 340 61 81 16660 49
AST-130-360-61 130 360 61 78 18720 52
AST-130-380-61 130 380 61 84 17480 46
AST-130-400-61 130 400 61 81 19600 49
